Results Grid
Information about all formed blocks ​for each analysis is displayed in the Results Grid ​according to the active Analysis Window. Each time the analyses are computed, the Results Grid at the bottom pane of the screen updates accordingly.
Different blocks can be viewed as models in the active Analysis Window by double-clicking a row in the Results Grid. The active block is highlighted yellow in the Results Grid.
To show/hide the Results Grid:
- Select Results > Show Results Grid
to toggle the Results Grid visibility.
Wedge Results Grid​
The following columns are available in the Wedge Analysis Results Grid:
- ID
- Factor of Safety
- Wedge Volume
- Wedge Weight
- Driving Force
- Resisting Force
- Joint 1 Info
- Joint 2 Info
- Basal Joint Info
Planar Results Grid
The following columns are available in the Planar Analysis Results Grid:
- ID
- Factor of Safety
- Wedge Volume
- Wedge Height
- Driving Force
- Resisting Force
- Joint Info
Toppling Results Grid
The following columns are available in the Toppling Analysis Results Grid:
- ID
- Factor of Safety
- Joint Info
Manage Columns
The visibility of any of the columns listed above can be toggled by selecting the Manage Columns
button at the top of the Block Information pane and then by checking/unchecking the column names in the left pane.
Filter Options
Filtering can be applied to blocks viewed in the Results Grid panel via the Filter Options
button.
Edit Filters
A handful of quick filter controls are available in the Edit Filter collapsible menu on the left of the Results Grid.
The quick filters include:
- Factor of Safety
- Volume (for Wedge/Planar)
- Weight (for Wedge/Planar)
Enter range values in the edit boxes or slide the sliders to specify the inclusive range of the numeric quick filters.​​
The Full Filter Editor allows users to define other filters not included in the quick filters or create more advanced filters using combinations of conditional statements to query the column data.
Saved Filters
After customizing a filter, it can be saved and accessed again from the Saved Filters collapsible menu on the left side of the Results Grid.
Creating a Filter
To create a filter:
- Open Edit Filters
- Adjust the sliders to specify the range.
- Select Save Filter.
- The Save Filter dialog will open and state the name of the filter.
- Select either Save As New Filter or Overwrite Existing Filter.
When a filter is applied:
- The bottom of the Results Grid pane will show the applied filter as checked.
- The listing of blocks in the Results Grid will only show blocks meeting the filter criteria.
To edit the filter:
- Select the Full Filter Editor button in the Edit Filters section
To clear the filter:
- Select the Clear Filter button from the Edit Filters section.
Export to CSV
The Export to CSV
option allows the user to export all or filtered data in the Results Grid panel to a CSV or Excel file.
Right-Click Options
Two options are available for users when right-clicking the Results Grid panel:
