Excavation Design Software

Model virtually any underground or surface excavation for civil, geotechnical, and mining applications. Get the tools with the capability to analyze stress, stability, and groundwater flow, as well as design and model excavation supports – all in either soil or rock.

RS2

2D Finite Element Analysis Software

Analyzes slopes, foundations, tunnels, and more using the shear strength reduction method for accurate stability assessments.

RS3

3D Finite Element Analysis Software

Analyzes complex 3D geotechnical models for civil and mining projects, perfect for both rock and soil.

RocTunnel3

3D Rock Stability Analysis for Underground Excavations

Determines valid block formations by intersecting joints in 3D space and calculates the factor of safety for each block using the 3D limit equilibrium method.

UnWedge

Underground 3D Wedge Stability Analysis Software

Visualizes underground excavations in rock containing intersecting structural discontinuities.

RSData

Strength and Stress Analysis Software

Analyzes rock and soil strength data and determines strength envelope parameters. Includes RocProp, a database of intact rock properties.

EX3

3D Stress Analysis Software

Utilizes the boundary element method for large-scale underground structures including mines, tunnels, and caverns.

RocSupport

Support Estimation Software

Uses ground reaction curves to estimate deformation in circular or near-circular excavations in weak rock and visualizes tunnel interaction with various support systems.

Dips

Graphical and Statistical Analysis Software for Orientation Data

Provides stereographic projection for the interactive analysis of orientation-based geological data. Capable of kinematic and jointing analysis.

CPillar

Crown Pillar Stability Analysis Software

Analyzes the stability of surface and underground crown pillars and laminated roof beds with a wide range of analysis methods.
