Vallcebre Landslide Stability Analysis Using Geophysical Data and Limit Equilibrium Methods in Slide3 and Slide2

Published on: Feb 06, 2023 Updated on: Nov 09, 2023 Read: 8 minutes

Landslides are complex bodies that are often made of heterogeneous geological materials and gradational physical properties. Due to the intricate nature of the landslides, traditional geotechnical methods may not provide you with detailed insights into rock and soil materials, and geomorphological and stability conditions.

This study presents a unique, reliable, and cost-effective approach to the stability analysis of a Spanish Pyrenees slow-moving landslide by combining Geophysical evaluation data into Rocscience’s 3D Limit Equilibrium program Slide3 for calculating the factor of safety. Further, a 2D analysis was also done on the sliding surfaces using Slide2 to compare and validate 3D results.

Geological Overview: Spanish Landslide Region

The Vallcebre landslide in the Pyrenees range, 110 km west of the Mediterranean Sea is situated in the Llobregat river basin. The geological compositions of the landslide include claystone, shale and layers of gypsum sliding above a thick limestone substrate. Most of the initial faults found in slopes around the landslide indicated its evolution over time.

The image shows the geological map and a digital elevation model of the Vallcebre landslide — Figure 1. (a) Location sketch and geological map of the studied zone. Modified from (ICGC, 2003); (b) Geomorphological sketch and digital elevation model of the Vallcebre landslide. Modified from (Cahyaningsih et al., 2019).

The Vallcebre landslide is particularly very sensitive to groundwater fluctuation and rainfall, therefore displacements can occur due to changes in water level. When water enters the landslide, it can change subsurface properties causing deformations and ultimately triggering landslide slope failure. A geophysical method like Electric Resistivity Tomography (ERT) can be a useful technique to determine the position of the water table and was used in this study to identify the effect of water on landslide dynamics.

Geophysical Analysis Methods

ERT: The Electric Resistivity Tomography (ERT) method is popular in terms of providing detailed imaging of the distribution of subsurface electrical resistivity. While this method was applied to the lower units of the landslide, a Syscal Pro resistivity meter with an array of Wenner-Schlumberger, a commonly used technique for soil resistivity measurements, was employed to collect geoelectrical data.

The electrodes and ground contact resistance readings were obtained for a total of 7 profiles in the landslide area, shown in Figure 2, which also outlines the results of four profiles from the SRT analysis.

SRT: The advantage of the Seismic Refraction Tomography (SRT) method over electrical methods is a direct relationship between porosity and acoustic velocities. However, when it comes to complex geological conditions, electrical techniques are way more effective for identifying the position of water tables.

The image shows the location of the geophysical surveys and lithological logs of boreholes — Figure 2. (a) Location of the geophysical surveys; (b) Simplified lithological logs of boreholes; (c) 142 Geological cross-sections A—A’ (Vallcebre area). Modified from (Corominas et al., 2005).

ERT and SRT Results

The results that were collected from the two geophysical analyses were interpreted through the inverted cross-sections from Wenner-Schlumberger (W-S) array. The electric resistivity variations along the ERT profiles outline the main material layers of the study area.

The image shows ERT inverted model resistivity cross-sections and their interpretation based on borehole lithological logs — Figure 3. ERT inverted model resistivity cross-sections and their interpretation based on the borehole 309 lithological logs.

These ERT cross-sections show low resistivity values in the upper portion and high resistivity values in the deeper zone consisting of clayey siltstone and limestone. The data obtained from SRT profiles were used to classify the lateral variation of the materials.

The image shows inverted seismic refraction tomography pseudo-sections with the corresponding 371 interpretation — Figure 4. Inverted seismic refraction tomography pseudo-sections with the corresponding 371 interpretation.

Finally, the results obtained through ERT and SRT analyses were compared by adding the closest lithological data and the comparison showed agreement between the two results.

The image shows an overlay of SRT, ERT and lithological logs results — Figure 5. Overlaying of SRT, ERT and lithological logs results.

Material Properties and Analysis Parameters

Using a unique set of data including boreholes, electric resistivity range of materials, and subsurface formations collected through seismic refraction profiles, a 3D geometry was created for analysis using the Limit Equilibrium Method (LEM) in Slide3. Further, a 2D LEM analysis was also conducted on the 3D cross sections of sliding surfaces and the results were compared.

Table 1. Geotechnical properties of materials used in Rocscience Slide3 software (Bedrosian et al., 2012; Cahyaningsih et al., 2019).

Unit name	Unit Weight (kN/m3)	Cohesion (kPa)	Phi (°)
Limestone*	20	-*1	-*1
Clayey Siltstone	18	0	14.7
Fissured Shales	19	0	11.8
Debris of Gravel	20	0	14.7

Limestone* does not have cohesion and friction value because it has been considered as an infinite strength material (Corominas et al., 2005, 2000).

Table 2. Analysis parameters used in Rocscience Slide3 software.

Group	Parameter	Value
	Unit weight of water	9.81 kN/m3
Convergence	Number of columns in X or Y	50
	Intercolumn force function	Half Sine
Surface Options	Search Methods Maximum Iterations Iteration tolerance	Cuckoo Search 30 0.0001

Landslide Stability Analysis with Limit Equilibrium Method

The Limit Equilibrium Method (LEM) of slope stability analysis is the most common and widely used technique for analyzing landslide stability. In this study, the LEM method was used for its simplicity, reliability and capability of providing insights into the spatial distribution of potential sliding surfaces of the transitional Spanish landslide.

3D Model Creation in Slide3: First, borehole data was imported into Slide3 using Borehole Manager tool for 3D geometry creation. Next, coordinates, formations, and water elevation for each borehole were defined.

Since ERT and SRT data had specific electric resistivity and velocity ranges for each material, both data types were divided into four different sets (specifying geological formations of the landslide) and saved as XYZ data grid. Benefitting from Slide3’s capability to generate surfaces from XYZ data, a 3D model of the landslide was built and evaluated.

3D LEM Analysis Results: Employing Slide3’s four 3D limit equilibrium methods of analysis including Bishop, Janbu, Spencer and Morgenstern-Price (GLE), a factor of safety of 0.7 was found in the vicinity of the landslide. In this case, four different methods were used to verify the results and accurately capture the instability of the landslide. All four methods outputted similar results – a factor of safety of 0.7 outlining the instability of the landslide region.

The image shows factor of safety variation map using different 3D limit equilibrium methods: Bishop method, Morgenstern and Price method (GLE), Janbu method and Spencer method. — Figure 6. Factor of safety variation map using different three-dimensional limit equilibrium methods: Bishop method, Morgenstern and Price method (GLE), Janbu method and Spencer method.

Slide2's 2D Analysis on 3D Cross-Sections

Three different cross-sections were generated from Slide3’s 3D model along the sliding surface and analyzed with the Slide2 engine available in Slide3 to compare, verify, and interpret 3D results through a simplified 2D version.

The image shows factor of safety variation along the sliding materials of three different cross-sections — Figure 7. Factor of safety variation along the sliding materials of three different cross-sections

Slide2’s 2D analysis has shown about 10-15% differences from the 3D analysis – the deviation of the factor of safety along the sliding units in the 2D analysis showed slightly higher values of about 10% for sections I & II, whereas the value for section III was about 15% which was lower than the 3D analysis. This minor difference between 2D and 3D analysis has commonly been found in some similar studies in the past.

The image shows factor of safety values of section I (a), II (b) and III (c) using 2D limit equilibrium methods in Slide2 — Figure 8. Factor of safety values of section I (a), II (b) and III (c) using two-dimensional limit equilibrium methods (Slide2 software), the analysis was performed using Bishop, Janbu, Spencer and GLE; (d) Location of section I, II and III.

Concluding An Integrated Approach to Landslide Stability Analysis

Slope stability analysis of the Vallcebre landslide using geophysical data in Slide3’s 3D LEM slope stability analysis has proven to be successful in calculating factor of safety for the critical sliding surface.
Using four different Limit Equilibrium Methods (Bishop, Janbu, Spencer and Morgenstern, and Price) available in Slide3 and Slide2, it was possible to reach a concrete approximation of the factor of safety which showed a good agreement between 3D and 2D results.
Further, the potential sliding surface showed that a landslide could occur between the lower and intermediate units.
Overall, this experiment set an example of a one-of-a-kind and very cost-effective approach to landslide stability analysis.

Read the full paper for a deep understanding of this unique experiment.

Thoughts from Rocscience: 2D and 3D Analysis Complement Each Other

When analyzing a complex and everchanging structure such as the Vallcebre landslide, a full 2D and 3D Limit Equilibrium assessment can provide you with comprehensive insights into the non-balanced forces, and magnitude and help evaluate the spatial distribution of the instability.

Two-dimensional analysis being a traditional method doesn’t always consider different geological materials along the slope region while a 3D analysis estimates the realistic representation of the slip surface of a slope. However, the level of data needed for a 3D analysis isn’t always available, this emphasizes the need for both 2D and 3D analysis.
